n-type chalcogenides by ion implantation

Hughes, MA; Fedorenko, Y; Gholipour, B; Yao, J; Lee, TH; Gwilliam, RM; Homewood, KP; Hinder, S; Hewak, DW; Elliott, SR; Curry, RJ

Abstract

Carrier-type reversal to enable the formation of semiconductor p-n junctions is a prerequisite
for many electronic applications. Chalcogenide glasses are p-type semiconductors and their
applications have been limited by the extraordinary difficulty in obtaining n-type conductivity.
The ability to form chalcogenide glass p-n junctions could improve the performance of
phase-change memory and thermoelectric devices and allow the direct electronic control of
nonlinear optical devices. Previously, carrier-type reversal has been restricted to the GeCh
(Ch¼S, Se, Te) family of glasses, with very high Bi or Pb ‘doping’ concentrations (B5–11
at.%), incorporated during high-temperature glass melting. Here we report the first n-type
doping of chalcogenide glasses by ion implantation of Bi into GeTe and GaLaSO amorphous
films, demonstrating rectification and photocurrent in a Bi-implanted GaLaSO device.
The electrical doping effect of Bi is observed at a 100 times lower concentration than for Bi
melt-doped GeCh glasses.
