Antero-posterior (AP) pelvis x-ray imaging on a trolley : impact of trolley design, mattress design and radiographer practice on image quality and radiation dose

Allsup, JR; England, A; Hogg, P

Abstract

Introduction: Physical and technical differences exist between imaging on an x-ray tabletop and imaging on a trolley. This study evaluates how trolley imaging impacts image quality and radiation dose for an antero-posterior (AP) pelvis projection whilst subsequently exploring means of optimising this imaging examination.
Methods: An anthropomorphic pelvis phantom was imaged on a commercially available trolley under various conditions. Variables explored included two mattresses, two image receptor holder positions, three source to image distances (SIDs) and four mAs values. Image quality was evaluated using relative visual grading analysis with the reference image acquired on the x-ray tabletop. Contrast to noise ratio (CNR) was calculated. Effective dose was established using Monte Carlo simulation. Optimisation scores were derived as a figure of merit by dividing effective dose with visual image quality scores.
Results: Visual image quality reduced significantly (p < 0.05) whilst effective dose increased significantly (p < 0.05) for images acquired on the trolley using identical acquisition parameters to the reference image. The trolley image with the highest optimisation score was acquired using 130 cm SID, 20 mAs, the standard mattress and platform not elevated. A difference of 12.8 mm was found between the image with the lowest and highest magnification factor (18%).
Conclusion: The acquisition parameters used for AP pelvis on the x-ray tabletop are not transferable to trolley imaging and should be modified accordingly to compensate for the differences that exist. Exposure charts should be developed for trolley imaging to ensure optimal image quality at lowest possible dose.

• Journal Article Type: Article
• Acceptance Date: Apr 1, 2017
• Online Publication Date: Apr 28, 2017
• Publication Date: Aug 1, 2017
• Deposit Date: Apr 4, 2017
• Publicly Available Date: Apr 28, 2018
• Journal: Radiography
• Print ISSN: 1078-8174
• Publisher: Elsevier
• Volume: 23
• Issue: 3
• Pages: 242-248
• DOI: https://doi.org/10.1016/j.radi.2017.04.002
• Publisher URL: http://dx.doi.org/10.1016/j.radi.2017.04.002
• Related Public URLs: https://www.journals.elsevier.com/radiography
